Part Location Diagram of WH01X10001 GE Socket Rod Support - White
See part 419 in the diagram
Replacing your General Electric Washer Socket Rod Support - White
( Grid squares measure 1x1 inch )

Socket Rod Support - White WH01X10001

Rated by 1 customers

?

Easy

15 - 30 mins

Ratings submitted by customers like you who bought this part.

?
$12.59
In Stock
Fix Number:
FIX268394
Manufacturer #:
WH01X10001
Manufactured by:
GE

Product Description

This part is a replacement socket rod support for your washer. The socket rod support is found at the top of the washer frame in the front part of the washer. It supports the suspension rod, so the rod can prevent the tub from shaking too much during operation. If your washer is shaking excessively or emitting an odd sound during use, it may be because the rod support is broken, and the suspension rod is not able to do its job. This part is made of white plastic and is sold individually.

Videos For installing this part.

Replacing your Socket Rod Support - White

Replacing your Socket Rod Support - White

Questions and Answers

We're sorry, but our Q&A experts are temporarily unavailable.
Please check back later if you still haven't found the answer you need.

View More View Less
Tub Dampening Strap
$9.60
In Stock
Rod and Spring Assembly - Green
$44.46
In Stock
Rod and Spring Assembly - White
$36.32
In Stock
Suspension Rod and Spring
$47.28
In Stock
Suspension Rod and Spring Assembly
$43.20
In Stock
Affresh Washing Machine Cleaner - 3 pack
$12.58
In Stock
Produce Preserver Filter
$21.50
In Stock
Affresh Dishwasher Cleaner Tablets - 6
$19.09
In Stock
Cooktop Cleaning Cream
$15.57
In Stock
Cooktop Cleaner
$17.74
In Stock
Affresh Cleaner
$19.09
In Stock

Installation Instructions Provided by Fix customers like you.

Average Repair Rating: 3.9 / 5.0, 1 reviews.
  • 1
Sort by:
Sorry, we couldn't find any existing installation instruction that matched.
Customer:
Conrad from Berwick, ME
Parts Used:
WH16X543, WH01X10001
Difficulty Level:
Easy
Total Repair Time:
15 - 30 mins
Tools:
Nutdriver
Noisy and movement
Removed control panel, front cover, and top cover. Lift the whole tub and motor assembly and put block of wood under to hold it up. Pop old rod out at the bottom by tapping with a hammer hand, and take the old rod seat out of the top frame, then put the new parts in. Do this on all four corners. I found it easier to do the back rods first . Remove the wood bock and seat the lower rods into position. Put the top cover on, control panel, and finally the front cover.
5 of 5 people found this instruction helpful.
Was this instruction helpful to you?
Thank you for voting!
  • 1

Model Compatibility

This part works with the following models:
Fix Number: FIX268394
Manufacturer Part Number: WH01X10001
Brand
Model Number
Description
General Electric
51451Y1WW
Washer
General Electric
51451Y2WW
Washer
General Electric
56021A0WW
Washer
General Electric
56031A0WW
Washer
General Electric
56041A0WW
Washer
General Electric
56051A0WW
Washer
General Electric
56121TBWW
Washer
General Electric
56220TBWW
Washer
General Electric
56221B0WW
Washer
General Electric
56221B1WW
Washer
General Electric
56221B2WW
Washer
General Electric
56221B3WW
Washer
General Electric
56231B0WW
Washer
General Electric
56231B1WW
Washer
General Electric
56231B2WW
Washer
General Electric
56231B3WW
Washer
General Electric
56241B0WW
Washer
General Electric
56241B1WW
Washer
General Electric
56241B2WW
Washer
General Electric
56241B3WW
Washer
General Electric
56251B0WW
Washer
General Electric
56251B1WW
Washer
General Electric
56251B2WW
Washer
General Electric
56411D0WW
Washer
General Electric
56411D5WW
Washer
General Electric
56411DAWW
Washer - Ge Washing Machine 56411daww
General Electric
56421D0WW
Washer
General Electric
56421D5WW
Washer
General Electric
56421DAWW
Washer
General Electric
57051A0WW
Washer
